55kw DC Fast EV Charger Wall Mounted

Customization:	Available
Nature of Source Flow:	Passive inverter
Certification:	CCC, ISO9001, RoHS, CE, SAA

📊 Basic Information

Model NO.

55KW DC

Output Power

501 - 1000W

Grid Type

Grid Inverter

Output Type

Single

Circuit Topologies

Push-Pull Type

Nature of Wave String

Sine Wave Inverter

Type

DC/AC Inverters

Input Voltage

70~280VAC

Output Voltage

220VAC-240VAC

Inverter Efficiency

93%

Maximum AC Charge

20/30/60A

Warranty

Three Years

Application

Home, Industrial, Commercial

Origin

China

📸 Product Display

⚙️ Technical Specification

Model & Rated Power	BD-EVPD2-60/240 Rated Power: 160kW / 240kW
Electrical I/O	Input: AC 380V±15%, 45-60Hz, 0-320A / 0-480A Output: DC200-1000V, 5-540A / 5-800A
Performance Metrics	Efficiency: >95% Power Factor: 0.9950 (above 50% load)
Installation & Dimensions	Routing: Down in and out Product Size: 820×60×1800mm Cable Length: 5m

🏢 Capabilities & Production

The focus is on the R&D and sales of civil charging equipment, with rich experience in the implementation of community charging projects. The production base has passed the ISO9001 Quality Management System Certification, with an annual capacity of 100,000 units. It focuses on promoting cost-effective civil charging piles. The overseas market covers emerging markets such as Southeast Asia and Africa, cooperating with local real estate developers and property companies.

❓ Frequently Asked Questions

What is an electric vehicle (EV) charging pile and how does it work?

An EV charging pile is a dedicated electrical device that supplies energy to recharge EV batteries. It connects to the grid, regulates voltage/current according to the vehicle's BMS, and delivers AC or DC power.

What is the difference between AC and DC fast charging piles?

AC piles (3.6kW–22kW) are slower and rely on the vehicle's onboard charger, ideal for home/office. DC fast piles (50kW–480kW) bypass the onboard charger using a built-in rectifier, providing rapid charging for public stations.

How do I choose the right power rating for my EV?

Check your EV's maximum supported power. For home use, 7kW–11kW AC is usually sufficient. For commercial use, calculate based on target time (e.g., 120kW DC can charge a 60kWh battery from 20% to 80% in ~30 mins).

What are the environmental requirements for installation?

The equipment operates reliably in humidity levels from 5% to 95% (non-condensing), making it suitable for various indoor and outdoor environments.

What is the energy conversion efficiency of these inverters?

Our charging solutions offer high efficiency, typically ranging from 93% to over 95% depending on the specific model and load conditions.

What applications are these charging piles suitable for?

These units are versatile and designed for home use, industrial facilities, and commercial charging plazas, supporting various grid types and requirements.
