📊 Basic Information
Usage
Electric Vehicle Charging
Product Name
2 in 1 Obc+Dcdc
Charger/DC Power
3.3kw/1kw
Output Voltage Range
200~450V
Production Capacity
1000PCS/Month
📦 Packaging & Delivery
Package Size
25.00cm * 23.00cm * 15.00cm
Package Gross Weight
5.500kg
🖼️ Product Visuals
📋 Technical Specifications Comparison
| Model |
Nominal Voltage |
VAC-DC Model |
Power |
VAC-DC Output (V) |
Voltage Range |
VAC-DC Current (A) |
DC-DC Model |
DC-DC Power |
| CD-MF01 | 72V | HK-MF-72-40 | 3.3KW | 72 | 50-107V | 35A | TDC-IY-72-12 | 1KW |
| CD-MF03 | 108V | HK-MF-108-32 | 3.3KW | 108 | 80~161V | 32A | TDC-IY-108-12 | 1KW |
| CD-MF04 | 144V | HK-MF-144-23 | 3.3KW | 144 | 95~202V | 23A | TDC-IY-144-12 | 1KW |
| CD-MF05 | 312V | HK-MF-312-10 | 3.3KW | 312 | 200~450V | 10A | TDC-IY-320-12 | 1KW |
| Model |
Cooling Type |
DC Input (V) |
DC Input (A) |
Max Input (A) |
DC-DC Output (V) |
DC-DC Output (A) |
Net Weight (kg) |
Dimension (CM) |
| CD-MF01 | Enforced Air | 72 | 14 | 23 | 14 | 72A | 5.5 | 40*35*21 |
| CD-MF03 | Enforced Air | 108 | 10 | 17 | 14 | 72A | 5.5 | 40*35*21 |
| CD-MF04 | Enforced Air | 144 | 8 | 13 | 14 | 72A | 5.5 | 40*35*21 |
| CD-MF05 | Enforced Air | 320 | 3.5 | 6.2 | 14 | 72A | 5.5 | 40*35*21 |
❓ Frequently Asked Questions
What are the primary functions of the CD-MF05 model?
The CD-MF05 is a 2-in-1 integrated unit that combines an On-Board Charger (OBC) and a DC-DC converter, specifically designed for electric vehicle charging systems.
What is the input voltage range supported by this device?
This unit supports a wide AC input voltage range from 90V to 264V, making it compatible with various power standards.
How does the cooling system work for these converters?
All models in this series utilize an enforced air cooling (fan-cooled) system to ensure stable performance and heat dissipation during high-power operation.
What are the communication baud rates for the CAN interface?
The device supports standard CAN communication with configurable baud rates of either 250K or 500K.
What is the protection level and durability of the unit?
The product is designed with high durability, featuring an IP67 rating as indicated in the technical description, suitable for demanding automotive environments.
What is the physical size and weight for shipping?
The individual package size is 25cm x 23cm x 15cm with a gross weight of approximately 5.5kg per unit.
